COBRA SPECIFICATIONS CONT.
• Clearance from plinth surface to top of
arm mount: 150-200mm preferred for arm wire training.
• Cartridge Weight Range: 0-20Grams – Adjusted by
Mass Addition Subtraction of Supplied Weight Adjustment
Kit. Fine tuned by 8 Gram sliding set screw for 0.01
Gram increments.
• VTA Adjust: – Yes
• Azimuth Adjust: - Yes
• Horizontal Natural Frequency: 8.1Hz
(Note: Calculated on Finite Element Analysis)
• Vertical Natural Frequency: 8.1Hz
(Note: Calculated on Finite Element Analysis)
• NULL POINTS: 66.0mm Inner 120.8mm Outer
• Audio Lead: Supplied with a 33 AWG pure copper litz
design as 1.5 meter standard in our preferred
configuration of single RCA Termination from Cartridge
Clip to RCA Male Connector. Other Arm leads are available
and are easy to replace and can be supplied on request.
• DIN Plugs: can be fitted as an optional extra.
• Complete Arm Weight: 1Kg Nominal
THE
COBRA
SPECS
