Coolbox FC75 - Operating and Display Elements

4.2 Operating and display elements
No.
Description
Description
1
Switches the cooler on or off when the button is
pressed for one or three seconds
2
Display
Press button to switch the cooler on
DC: DC connection is on
H/M/L: Battery voltage protection gear
℃/℉: Temperature unit symbol
: Large compartment cooling operation
: Small compartment cooling operation
: Compressor is on
: Bluetooth is on
MAX : Maximum cooling mode
ECO: Energvy-saving cooling mode
3
Press the "+" button to increase the
temperature gauge or function selection.
Press the "-" button to decrease the
temperature gauge or function selection.
Press the "-" and "+" buttons at the same time
for 3 seconds to set temperature
compensation.
4
Press “ ”to select the function or save the
setting memory
Display panel:
DC12.6V H M L
-22 -22
º C º C
MAX/ECO
1 2 3 12 4 13 14 11
10879
5 6
09
