Charging Current Guidelines
AC Input Circuit
Branch Breaker
or fuse size
(Amps)


Charger DC Current Setting (Amps)
Maximum By-pass AC Current
Available (Amps)


12-110-1000-B2
12-110-1800-B4,
12-110-1000-B4
12-110-1000-B2
12-110-1800-B4,
12-110-1000-B4
15
2 2 13.5 13.5
5 10 12.5 11
10 20 11 8.5
20 40 8.5 3.5
20
2 2 18.5 18.5
5 10 17.5 16
10 20 16 13.5
20 40 13.5 8.5
30
2 2 28.5 28.5
5 10 27.5 26
10 20 26 23.5
20 40 23.5 18.5
   


Table 3-1 Charging Current Guidelines
