UtilitytoInverter

ACinputrecoveryfrom
InvertertoUtility

100VAC
UtilitytoInverterand
InvertertoUtility
hysteresis

5VACminimum
MaximumACoutputby‐
passcurrent

20Arms
ACtransfertime–
InvertertoUtility

20Secondsnominal
ACtransfertime–Utility
toInverter

<50ms
Timedelayontransfer
fromInvertertoUtility

20s+/‐2s
 Voltages+/‐5V
Batter
y
Charger
ACinputoperatingrange
95–135VAC
ACinputrangewithfull
power

105V–135VAC
ACinputcurrentwithno
load

<0.50Arms
Inputcurrentfullload <6Arms(12‐110‐1000‐B2) 11.5Arms(12‐110‐1000‐B4,12‐110‐1800‐B4)
ACinputfrequency 60Hz+/‐1Hz
OperatingTemperature
Range

0Cto+50C(Allowfor1.5Adcchargecurrentreductionabove+40C)

DC Output Voltage:


Battery Type
Setting

O/P Voltage VDC (Tolerance +/- 0.2Vdc)

Bulk

Absorption Float

Fixed 13.5

13.5

13.5 13.5

Flooded

14.4

14.4 13.5

Gel

14.3

14.2 13.8

AGM

14.4

14.3 13.4
