Cooper Bussmann 1000W - Temperature and Battery Protection

38

Model DCOutputFuse
12‐110‐1000‐B2 2x25A(AutoBlade)
12‐110‐1000‐B4

12‐110‐1800‐B4

3x25A(AutoBlade)

OverTemperatureProtection




Location Condition

ChargerTransformer
>95°C Max.Chargecurrentreducedtohalfoffullload
>100°C Max.Chargecurrentreducedto0A
ACTransferRelay >70°C Systemshutdown(noauto‐reset)
Note:Max.chargecurrentresumesnormallevelwhenChargerTransformersensor
temperaturedropsbelow90°C



Location
Warning(°C)
Errorcode/Audio
alarm
Shutdown(°C)
ErrorCode/Audio
alarm
On Off On Off
RectifierDiode >90 <88 E07/

Beep@0.33Hz
>95 <80 E04/

Beep@1Hz
Extrusion >63 <60 >60 <56

Note:Overtemperatureshutdownofthesesensorsisautoreset.Sensortemperature
toleranceis+/‐5°C


ReverseBatteryProtection


Model DCInputFuse
12‐110‐1000‐xx 4x30A(AutoBlade)
12‐110‐1800‐xx 8x30A(AutoBlade)


Note:ReversepolarityonDCInputwillopentheDCinputandfaultindicationfuses.Fusesarenon‐
replaceable,exceptatfactory.



