S280-70-3
27
CI4
TB3
1
3579 11 13 15 17 19 21
CI5
CI6
CI7 CI8
CI9
CI10
CI11
CO5
CO6
TB4
2
46 810121416
18
20
CI4 CI5 CI6 CI7 CI8 CI9
CI10
CI11
CO5
CO6
13
5
7911 13
CO7 CO8
CO9 CO10 CO11
CO12
2
46
8
10
12
CO7 CO8 CO9
CO10
CO11
CO12
Supervisory Ground Trip Block
Supervisory Reset Targets
Supervisory Non-Reclose
Unassigned
Remote Alternate Profile 2
Remote Alternate Profile 1
Remote Alternate Profile 3
Non-Reclosing
Status
(Normal
Reclose)*
Remote Normal Profile
Alarms
Status
(No Alarms)*
Alternate
Profile 1
Status
(Not in
Alt 1
Profile)*
Normal
Profile
Status
(Not in
Normal
Profile)*
Alternate
Profile 2
Status
(Not in
Alt 2
Profile)*
Frequency
Alarm
(Frequency
Normal)*
Alternate
Profile 3
Status
(Not in
Alt 3
Profile)*
Voltage
Alarm
(Voltage
Normal)*
*Relay Contacts shown
for Indicated Status
Customer Wiring
Remote/Supervisory Common
Customer-Supplied
Voltage Inputs**
**Whetting voltage is available from the
Form 6 Recloser Control on Terminal Block
TB9. Refer to Figure 22.
Figure 21.
Form 6 pole-mount recloser control Discrete Interface Board accessory default supervisory input control and out-
put status contacts.
IMPORTANT
Shielding and Surge Protection of
Supervisory Cables
All supervisory operation and control monitor leads must
be protected within shielded cables. Refer to Figure 22.
NOTICE: External leads must be shielded and the shield
must be grounded at both ends. Terminate each lead with
a 320VAC, 150 Joules metal oxide varistor (MOV), or
equivalent, at the remote end. Attach MOV’s between the
leads and ground. Failure to properly shield and protect
leads can result in equipment damage and/or uninten-
tional operation.
