• Insert a barrel nut into each of the headboard brace. The hash mark on the front of the nut should be aligned
vertically.
• Insert the 3” Allen Bolts through the underside of the deck and into the barrel nuts. Fully tighten each bolt
with the Allen Wrench.
• Once the braces are in place, retighten the four bolts on the back of the headboard panel.
• For the split headboard version, repeat Steps 5 and 6 for the other headboard assembly.
Headboard Assembly - Solid or Split Headboards
Brace
Astrid Bed - assembly instructions
Step 5
Step 6
www.copelandfurniture.com
• Slightly loosen all Allen bolts on the back of the headboard
assembly(s). Bolts must be loose before proceeding.
• Insert the vertical headboard braces onto the pockets of the
deck. This will be a snug fit.
3” Allen Bolts x4
Barrel Nuts x4
Note on Split Headboard Version: To preserve visual
continuity of the wood grain, the panels of the Split
Headboard version have been cut from a single larger
panel. Each of the two headboard assemblies has a
mark on the bottom of one of the vertical braces. For
each assembly, the brace with the mark should be
positioned toward the center of the bed.
Brace with Mark –
toward center of bed
