CORBERO FC1801I/1 - Control Panel

10
Colocar a presión el cubrejuntas entre el aparato y
el mueble.
D724
D
C
D723
Empujar el aparato en el hueco hasta que el perfil
superior (A) llegue a tope con el mueble.
A
D023
PR01
540
50
3
2
1
Es necesario además que el hueco tenga un
conducto de ventilación con estas medidas:
profundidad 50 mm
ancho 540 mm
Instrucciones para el encastrar
Dimensiones del hueco
Altura 1780 mm
Profundidad 550 mm
Anchura 560 mm
Para una adecuada ventilación seguir las
indicaciones de la Fig.
50 mm
min.
200 cm
2
200 cm
2
min.
D567
Abrir la puerta y adosar el aparato contra el lado del
mueble al lado opuesto a la bisagra de la puerta.
Fijar el aparato con los 4 tornillos en dotación. Colo-
car el zócalo de aireación (C) encajándola a presión
y colocar la tapa (D) en posición.
15
Control panel
A. Pilot light
B. SUPER operating control light
C. Warning light
D. Normal/Super (quick-freezing) switch
E. Thermostat knob
1
2
3
4
5
6
O
N
S
S
EABC D
Operation
Insert the plug into the wall socket. The pilot light will
light up, indicating that the appliance is powered.
Turn the thermostat knob, clockwise, beyond the
«O» (STOP) position. The freezer will start to
operate.
To stop operation, simply turn the thermostat knob to
position «O».
Temperature regulation
The temperature is automatically regulated and can
be increased to achieve a higher temperature
(warmer) by rotating the thermostat knob toward
lower settings or reduced (colder) rotating the knob
towards higher settings.
However, the exact setting should be chosen
keeping in mind that the temperature inside the
refrigerator depends on:
• room temperature;
• how often the door is opened;
• the quantity of food stored;
• location of appliance.
A medium setting is generally the most suitable.
Freezing fresh food
The 4-star compartment is suitable for long term
storage of commercially frozen food and for freezing
fresh food.
To freeze fresh foods allow it to run on the fast
freeze setting for at least 24 hours before loading
food.
Place the food to be frozen in the upper in the
freezer compartment as this is the coldest part.
Use of the freezer
Quick-freezing
For quick-freezing, turn the knob (D). The quick-
freezing indicator light (B) will then light up.
Warning light (C)
The temperature alarm light turns on automatically
whenever the temperature within the freezer rises
above a certain value which might endanger
satisfactory long-term conservation.
It is perfectly normal for the temperature alarm light
to remain lit up for a short time after the freezer is
initially turned on. It will remain lit up until the
optimum temperature for the conservation of frozen
food is attained.
Storage of frozen food
When first starting-up or after a period out of use,
before putting the products in the compartment let
the appliance run for at least two hours on the fast
freeze setting, then turn the thermostat knob to the
normal operating position.
Important
If there is a power failure when food is in the
freezer, do not open the door of the freezer
compartment. The frozen food will not be
affected if the power cut is of short duration (up
to 6-8 hours) and the freezer compartment is full,
otherwise, it is recommended that the food
should be used within a short time (a
temperature increase of the frozen food
shortens its safe storage period).
