Page #9 background imageLoading...
Page #9 background image
9
This antenna can support two TVs at the same time. Simply connect an
additional coaxial cable between the power supply box output connector
and your second TV.
Antenna Specifications:
25’ coaxial cable
Easy install and setup
Remote control included
Built-in noise circuit
Built-in high-gain booster
360˚ motorized rotation
UHF: 470-606MHz I 23±2dB
Impedance: 750Ω I F-connector
Noise gure: 2.5dB
Max output level: 105d BIV
Main voltage: AC-120 / 60Hz
Operating temperature: 14°F - 122°F
Weather resistant
Pole Specifications:
Great for mounting indoor and outdoor antennas, satellite dishes and
more.
Outer diameter: 1”
Pole length: 16.5”
Material: iron
Mounting hardware included
