7
TD 218
ENDURO 300 (ED300) (POST-MIX)
Item
No. Part No. Name
1 29303 Plate, Motor Mount
2 29654 Plate, Adjustable, Motor
3 30794 Heater, Motor
4 32498 Motor
5 51859 Seal, Motor Shaft
6 51860 Gasket, Motor
7 70018 Hex Nut, 1/4-20
8 70043 Washer, Flat, 1/4
9 70048 Washer, Lock, 1/4
10 70257 Screw, Phil Truss Hd, 1/4-20 By 1/2-In.
Long
11 70260 Screw, Phil Rd. Hd., 1/4-20 By 1-In.
Long
12 70341 Spring, Gate
13 70992 Receptacle, 1/4-turn
14 70993 Retainer, 1/4-turn
15 70994 Stud, 1/4-turn
9
14
1
2
3
4
5
6
7
8
9
10
11
12
13
15
8
MOTOR COMPONENTS
Item
No. Part No. Name
32954 Gate Solenoid Ass’y
1 28172 Plate, Solenoid Mounting
2 29173 Arm, Gate Lift
3 32957 Solenoid
4 50752 Isolator
5 50754 Bearing, Gate Arm
6 70162 Screw, No. 8-32 By 1/4-In. Long
7 70015 Hex Nut, No. 10-32
1
2
34
5
6
7
GATE SOLENOID ASSEMBLY
