ED Ice Maker Adapter Kit Installation Instructions Manual
© 2016, Cornelius Inc. - 5 - Publication Number: 629087971TENS
13. Apply a continuous bead of NSF International (NSF) listed silastic sealant (Dow 732 or equivalent) to seal the ice
maker to the top of the adapter lid. All excess sealant must
be wiped away immediately.
14. Install the ice maker mounting brackets on the back of the ice maker by drilling 9/64” diameter holes, using one of
the two supplied brackets as a template, into the rear of the ice maker and the rear of the adapter lid.
Use extreme care no to drill into any ice maker components.
Secure the Icemaker to the adapter lid using the #8 self drilling and mounting brackets provided.
15. Re-connect electrical power to the dispenser.
16. Verify function and operation of both Icemaker and dispenser.
