SPECIFICATIONS (Continued)
Standard Settings
Microprocessor-based preset functions can store 32 sets of geometry settings
incluexcept the standard settings. The following industrial standard settings have
been pre-programmed by the factory.
Table 5. Standard Settings
No. Video Mode Name
(with Resolution and Vertical Frequency)
Horizontal
Frequency
p1500 p1600
1
VGA 640  480 - 60 Hz
31.47 kHz

2
VGA 720  400 - 70 Hz
31.47 kHz

3
VESA 800  600 - 85 Hz
53.67 kHz

4
VESA 1024  768 - 85 Hz
68.68 kHz

5
VESA 1280  1024 - 85 Hz
91.15 kHz

6
VESA 1600  1200 - 85 Hz
106.25 kHz

7
CPT 1600  1280 - 80 Hz
106.25 kHz

8
CPT 1600  1280 - 87 Hz
114.90 kHz

9
CPT 1600  1200 - 92 Hz
114.90 kHz

10
CPT 1856  1392 - 71 Hz
102.77 kHz

11
VESA 1920  1440 - 75 Hz
112.50 kHz

The following industrial standard settings have been pre-loaded by the factory.
Table 6. Standard Settings (Pre-loaded)
No. Video Mode Name
(with Resolution and Vertical Frequency)
Horizontal
Frequency
p1500 p1600
1
VESA 640  480 - 75 Hz
37.50 kHz

2
VESA 640  480 - 85 Hz
43.27 kHz

3
VESA 800  600 - 75 Hz
46.88 kHz

4
VESA 1024  768 - 75 Hz
60.02 kHz

5
VESA 1280  1024 - 75 Hz
79.98 kHz

6
VESA 1600  1200 - 75 Hz
93.75 kHz

