IMPORTANT SAFEGUARDS
1. When using electrical appliances, basic safety precautions should always be followed including the
following:
2. Read all instructions.
3. Close supervision is necessary when any appliance is used by or near children.
5. Avoid contacting moving parts.
6. Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions, or is
dropped or damaged in any manner. Return appliance to the nearest authorized service facility for
examination, repair or electrical or mechanical adjustment.
injury.
8. Do not use outdoors
9. Keep hands, hair, clothing, as well as spatulas and other utensils away from beaters during operation to
reduce the risk of injury to persons, and/or damage to the mixer.
SAVE THESE INSTRUCTIONS
Cleaning
........................................................... 13
Operating Instructions
6
How To Use:
Before using, the tanks and taps of the
appliance should be cleaned carefully
Refilling
To ensure correct usage of the machine ensure
that the liquid level of the tank does not go
below 3-4 Qt (please use the level lines on the
tank for reference).
1. Mix product in a separate container (FIG. 2).
2. Make sure to unplug the appliance before
4. Do not let liquid level exceed the “MAX” level
line (FIG. 3).
Beverage Temperature Adjustment (FIG.5)
To adjust the temperature of each individual bowl,
lift up the plastic cover on left side of
the unit. Bowl 1 is on the left hand side of the unit
when looking from the front.
1. Turn on the main switch on the right hand of the
unit. The main power light (A) will now
indicate on the digital control.
2. To set the temperature of bowl no.1
press the button marked 1 twice. The indicator
lamp under bowl 1 at the top of the display will now
Adjust the arrow keys to set the desired temperature
and then press “set”. The temperature range may
be set between 2°C and 8°C.
The control temperature for bowl 1 is now set.
Repeat the process using the buttons marked 2
and 3 to set the temperature of the remaining
bowls.
3. When in operation the unit will automatically
display the actual temperature of each bowl for 2
seconds as indicated by the lamp beneath the bowl
symbols.
Fig. 5
A
C
