13 of 14CORRADI SRL  USER MANUALRev. 1 - 5.2018
Palladia®
TABLES
Table 1 - Wind resistance classes according to EN 13561
Class*
Nominal pressure
of the wind
Equivalent wind speed
(indicative)
Equivalent Beaufort scale
(indicative)
Weather conditions
(indicative)
Wind eects
(indicative)
0 Not defined, the product is not certified
1 Up to 40 N/sq m Up to 28 km/h 4 Moderate breeze Dust and loose paper raised, small branches begin to move
2 Up to 70 N/sq m Up to 38 km/h 5 Fresh breeze Small trees begin to sway
3 Up to 110 N/sq m Up to 47 km/h 6 Strong breeze Large branches in motion, umbrella use becomes difficult
4 Up to 170 N/sq m Up to 59 km/h 7 High wind Large branches in motion, effort needed to walk against the wind
5 Up to 270 N/sq m Up to 74 km/h 8 Gale Tree branches break, it is very difficult to walk outdoors
6 Up to 400 N/sq m Up to 91 km/h 9 Strong gale Tiles blow off roofs
Model No. of runners Width Projection
Palladia® and Palladia® wall-to-wall pitched
2 500 650
3 900 650
4 1300 650
5 1300 650
Palladia® and Palladia® wall-to-wall at, canvas with standard deection
2 350 600
3 700 600
4 1050 600
Palladia® and Palladia® wall-to-wall at, canvas with trapezoidal deection
2 500 650
3 800 650
4 1200 650
Palladia® and Palladia® wall-to-wall at, stretched canvas with spacers
2 500 600
3 800 600
The dimensions refer to the entire framework. To calculate the area of the surface covered by the fabric of Palladia® subtract 12 cm from the width and 22 cm from the projection. To calculate the area of the surface covered by the fabric
of Palladia® wall-to-wall subtract 12 cm from the width and 10 cm from the projection.
Values in cm of the maximum size with single canvas
Table 2 - Maximal dimensions
Table 3 - Maximum load
Maximum load in daN (1daN ≈ 1kg) on the single dowel (considering 2 dowels with counterplate (optional) or 4 dowels without counterplate, for each foot support and 2 dowels per wall support) tensile and shear (not combined) for
a maximum wind speed of 49 km/h (Class 3 according to EN 13561).
Width (cm)
200 250 300 350 400 450 500 550 600 650 700 750 800 850 900 950 1000 1050 1100 1150 1200 1250 1300
250 35 41 47 53 59 65 76 82 88 94 100 106 112 118 124 90 94 98 102 106 110 114 118
300 40 47 54 61 68 75 88 95 102 109 116 123 130 137 144 104 109 114 118 123 128 132 137
350 46 54 62 70 78 86 100 108 116 124 132 140 148 156 164 119 124 129 135 140 145 151 156
400 51 60 69 787 87 96 112 121 130 139 148 157 166 175 184 133 139 145 151 157 163 169 175
450 56 66 76 86 96 106 123 133 144 154 164 174 184 194 204 147 154 161 167 174 181 187 194
500 61 72 83 94 105 117 135 146 157 168 179 191 202 213 224 162 169 176 184 191 198 206 213
550 67 79 91 103 115 127 147 159 171 183 195 207 219 232 244 176 184 192 200 208 216 224 232
600 72 85 98 11 124 137 159 172 185 198 211 224 237 250 263 190 199 208 216 225 234 243 251
650 77 91 105 119 133 147 171 185 199 213 227 241 255 269 283 205 214 223 233 242 252 261 270
Projection (cm)
2 runners 3 runners 4/5 runners
