OOppeerraattiinngg IInnssttrruuccttiioonnss
CORREX
®
UP 2.3-919
22.. IImmppoorrttaanntt iinnffoorrmmaattiioonn ccoonncceerrnniinngg tthhee uussee ooff tthhee pprreesseenntt
ooppeerraattiinngg IInnssttrruuccttiioonnss
Read this information
bbeeffoorree rreeaaddiinngg tthhee OOppeerraattiinngg IInnssttrruuccttiioonnss..
22..11 SSccooppee ooff aapppplliiccaattiioonn
The present fitting and operating Instructions is applicable to the impressed-
current anode system
CCOORRRREEXX
®®
UUPP 22..33--991199
including the components shown
in the Annex.
The manual covers the following mountings:
Sleeve mounting
with screw G ¾"
with screw G 1"
with screw G 1¼"
with screw ¾"x14NPT
Insulated-hole mounting
ith M8 thread bolt for 10.5 mm fitting bore
22..22 AAnnooddee ttyyppeess ttoo bbee uusseedd
The impressed-current anode system CORREX
®
UP 2.3-919 is available with
different types of anodes. Information about which type of anode is suited to
which type of hot-water tank can be obtained from the storage tank manufac-
turers who will also provide information on the length and the number of ano-
des that can be installed in the storage tank. This is particularly important if
older storage tanks are to be retrofitted with anodes. The corresponding spe-
cifications of the storage tank manufacturer must be respected.
22..33 FFiittttiinngg pprriinncciippllee
All fitting instructions and sketches only show the fitting principle in schematic
form. Install CORREX
®
UP only if the actual fitting conditions correspond to
what is shown on the schematic drawings or to what can be unambiguously
inferred from them.
Do not install CORREX
®
UP anodes if this is not the case.
22..44 TTeecchhnniiccaall cchhaannggeess
The shapes and forms of the individual components can be changed at any
time without prior notice, especially if such changes are owed to technical
improvement or if so requested by the customer.
