CORREX UP 2.3-919 User Manual

OOppeerraattiinngg IInnssttrruuccttiioonnss
CORREX
®
UP 2.3-919
mitted as actual voltage to the potentiostat where the actual voltage is com-
pared to the reference voltage defined by the potentiostat. The protective cur-
rent supplied is then adjusted in such a way that the actual tank potential cor-
responds to the reference potential.
66 SSccooppee ooff ssuuppppllyy
66..11 CCOORRRREEXX
®®
UUPP 22..33--991199 ssccooppee ooff ssuuppppllyy ffoorr sslleeeevvee mmoouunnttiinngg
Check by comparison with the table below and the illustration in chapter 1.2
that the parts and components supplied are complete and intact before instal-
ling them.
Item Number Description
1 1 Plug-in potentiostat with pilot lamp
2 1 Titanium anode with insulated screw fitting set
3 1 Connecting cable with connectors
4 1 Operating Instructions
66..22 CCOORRRREEXX
®®
UUPP 22..33--991199 ssccooppee ooff ssuuppppllyy ffoorr iinnssuullaatteedd hhoollee mmoouunnttiinngg
Check by comparison with the table below and the illustration in chapter 11.2
that the parts and components supplied are complete and intact before instal-
ling them.
Item Number Description
1 1 Titanium anode with thread bolt and sealing disc
2 1 Plug-in potentiostat with pilot lamp
3 1 Connecting cable with connectors
4 1 Small bag containing:
1 Seal (Viton)
1 Diode board
1 Insulation sleeve M8x2
2 Hex nuts M8, galvanized
1 Tooth lock washer with tab connector 6.3 x 0.8 mm
5 1 Operating Instructions
