OOppeerraattiinngg IInnssttrruuccttiioonn
CORREX
®
UP 2.3-919
66..33 CCOORRRREEXX
®®
UUPP 22..33--991199 ssccooppee ooff ssuuppppllyy wwiitthh mmoouunnttiinngg kkiitt ffoorr rreettrrooffiittttiinngg
The CORREX
®
UP 2.3-919 system with mounting kit for retrofitting can be
alternatively used for:
sleeve mounting
insulated-hole mounting.
Check by comparison with the table below that the parts and components
supplied are complete and that the small bag is intact.
Number Item Description
1 Titanium anode with thread bolt and seal washer
1 Plug-in potentiostat with pilot lamp
1 Connecting cables with connectors
1 Mounting kit in small bag containing:
1 1 Seal
1 2a Screw fitting G ¾"
1 2b Screw fitting G 1"
1 2c Screw fitting G 1¼"
1 3 Insulation sleeve, small
1 4 Insulation sleeve, large
1 5 Diode board
1 6 Tooth lock washer with tab connector
2 7,8 Nut M8, galvanized
1 9 Flat nut M8, galvanized
1 Operating Instructions
The item numbers of the mounting kit correspond to the numbering in the
annex 'Mounting kits for retrofitting - arrangement of parts'
NNoottee::
The mounting kit for sleeve mounting requires prefitting of the screw fit-
ting set in acc. with chapter 7.1.2.1. The mounting kit for insulated hole moun-
ting is used as described in chapter 7.2.2.
30
0425_Bed.anl_UP_Innen_gesamt.qxd 25.05.2006 19:14 Seite 30
