OOppeerraattiinngg IInnssttrruuccttiioonn
CORREX
®
UP 2.3-919
4. Slide the Viton seal (
44
) over the thread bolt of the titanium anode (
11
) and
pass the anode from the inside of the tank through the fitting bore.
5. Use the insulation sleeve M8x2 (
55
) for centering the M8 stud in the 10.5 mm
bore of the flange-type cover.
6. Fasten the titanium anode together with the diode board (
66
) and the hex nut (
77
).
NNoottee::
The screw fitting must be pressure-tight. The tightening torque is 6
Nm. Use a torque wrench.
7. Fit the Tooth lock washer with tab connector 6.3 x 0,8 mm (
88
) and fasten
with the hex nut (
99
).
8. Refit the flange-type cover on the tank.
9. Fasten the spade terminal (
1111
) at the end of the cable labelled "ground
connection tank" under the earthing screw of the tank. If the tank has no
earthing screw,
tthhee ggrroouunndd ccoonnttaacctt mmuusstt bbee eessttaabblliisshheedd bbyy ootthheerr rreelliiaabbllee
mmeeaannss..
Without a perfectly conducting galvanic connection, the
CORREX
®
UP system cannot perform its function.
10. Push the other connector at the tank end of the cable (
1122
) - in this case
the receptacle 6.3x0.8 mm - on the tab terminal of the Tooth lock washer
of the anode.
11.Push the two different flat connectors (
1133
) and (
1144
) at the other end of the
connecting cable on tyhe connectors in the opening (
1155
) of the plug-in
potentiostat. Push the larger connector (6.3 x 0.8 mm) on the larger tab
and the smaller one (4.8 x 0.8 mm) on the smaller tab of the plug-in
potentiostat.
12.Plug the potentiostat (
22
) into a 230 V mains socket.
13.Fill the storage tank with water and check for leaks.
14.
RReeqquuiirreedd ffuunnccttiioonn cchheecckk::
The correct polarity must be checked by
measuring magnitude and sign of the drive potential applied with a DC-
voltmeter (e.g. digital multimeter or CorroScout
®
500); cf. chapter 9.2 (
11
).
The drive potential applied must be U > +2.3 V DC, when the tank is
connected with the negative input and the titanium anode with the positive
input of the measuring instrument.
15.Check the pilot lamp in the potentiostat housing.
NNoottee::
The CORREX
®
UP system becomes functional only after the tank has
been filled with water.
Pilot lamp (
1166
) green: mains supply established and CORREX
®
UP ready
to operate.
Pilot lamp (
1166
) off: probably no mains voltage.
Pilot lamp flashing red: malfunction of the system. In this case, the
checks described in chapter 9 must be performed.
36
