User Manual CORREVIT
®
SFII P Sensor
© 2008 CORRSYS-DATRON Sensorsysteme GmbH, Wetzlar, Germany D062-50-01-04E 02/08
7
Application
Features
• Small and lightweight - just 250 g
• Developed for measurement of tire slip angle
• Adjustable filter time (unfiltered, 8 ... 512 ms)
• Speed linearity - desired distance < ± 0.5 %
Distance linearity < ± 0.2 %
• Improved features by application of advanced DSP technology
• Mounting angle correction via software
• Direct connection to PC or other evalutation systems
• Illumination by long-life, high-power infrared LEDs
• Signal outputs: analog -10 ... 10 V
digital 0-1000 pulses/m
CAN Bus V2.0B
USB 2.0 or RS232
• Negligible service and maintenance requirements as a result of durable technology
• Tested and used under extreme environmental conditions
The compact, lightweight CORRSYS-DATRON SFII P Sensor is designed for use in dynamic vehicle
testing applications that require highly accurate measurement of the following variables:
• Distance
• Speed
• Angle
• Longitudinal speed
• Transversal speed
