3. Technical Data
Performance Specifications
Speed range: 0.3 ... 250 kph
Distance resolution: 2.08 mm
Uncertainty of measurement*: < ± 0.2%
Speed linearity - desired distance < ± 0.5 %
Distance linearity: < ± 0.2 %
Working distance and range: 180 +/-50 mm
Angle range: ± 40°
Angle resolution: ± 0.1°
Outputs
CAN Bus: CAN V2.0B - switchable terminating
resistor (Intel or Motorola Format)
Analog Outputs: VI, V
L
, V
q
, β ±10V each
(16 bit resolution)
Digitale Outputs: IVI, V
L
, V
q
, β
USB: USB 2.0 or RS232
System Specifications
Power supply: 10,5 V ... 24 V; 28 W (12 VDC)
Temperature range: operation: -25 ... 50°C
storage: -40 ... 85°C
rel. humidity: 5 ... 80%, non condensing
System Protection of the sensor head: IP 67
Illumination: IR-LEDs, 850 nm, laser class 1M
Dimensions of the sensor head (l x w x h): 100 x 33 x 45 mm (without plug)
Weight sensor head: 250 g
Dimensions of the electronics (L x H x B): 130 x 86 x 33 mm
Weight of the electronics: approx. 490 g
Schock: 50 g half-sine, 6 ms
Vibration: 10 g, 10 ... 150 Hz
USB interface for connection to the PC, automatic sensor identification, function control.
*with calibration on the test surface
INVISIBLE RADIATION FROM LIGHT EMITTING DIODES!
DO NOT OBSERVE WITH OPTICAL INSTRUMENTS!
LASER CLASS 1M
IN COMPLIANCE WITH
DIN EN 60825-1:2001
