PSU MANUAL
Introduction
Corsair power supplies are designed for worry-free compatibility for your desktop PC
system build or upgrade. With the features to be expect from a premium power supply, it’s
a great choice for systems where continuous and reliable power delivery and low noise are
essential.
Your Corsair power supply is packed with the latest technology and features:
• CX750, CX750M, GS, TX, TX-M, GS, CS-M, HX, AX and AXi Series support the latest
ATX12V2.4 standard and is backward compatible with ATX12V2.31 and earlier, as well as
ATX 2.2 and earlier systems.
• CX600, CX600M and lower wattages in the CX and CX-M Series and VS Series support
the ATX12V3.1 and is backwards compatible with all earlier ATX12V systems as well.
• All Corsair power supplies feature a thermostatically controlled intake fan that will vary
fan speed in response to temperature. The result is a quieter power supply at low loads.
• Corsair’s GS, TX, TX-M, RM, HX, AX (not including AX1200) and AXi all feature a Zero
RPM fan mode. At low loads, the intake fan will not spin, allowing the power supply to
operate in absolute silence.
• All of Corsair’s power supplies are at least 80% ecient at loads of 10% and greater.
• 0.99 Active Power Factor Correction provides clean and reliable power.
• A dedicated single +12V rail oers maximum compatibility with the latest components.
• Over-voltage and over-power protection, under-voltage protection, and short circuit
protection provide maximum safety to your critical system components.
• Extra-long cables support full tower chassis.
• Cables are either sleeved or are flat ribbon-style for improved aesthetics and better
airflow
• Modular units, such as the CX-M, TX-M, CS-M, RM, HX, AX and AXi, allow users to remove
cables. This makes installation easier and allows the customer to eliminate unused cables,
which reduces cable clutter within the chassis.
• Up to a seven year warranty and lifetime access to Corsair’s legendary technical support
and customer service.

Corsair CX750M Specifications

General

Total power	750 W
Input current	10 - 5 A
AC input voltage	100 - 240 V
AC input frequency	47 - 63 Hz
Combined power (-12V)	3.6 W
Combined power (+3.3V)	130 W
Combined power (+5Vsb)	15 W
Max output current (+12V)	62 A
Max output current (-12V)	0.3 A
Max output current (+3.3V)	20 A
Max output current (+5Vsb)	2.5 A
Cabling type	Semi-Modular
ATX Power connector (24-pin)	Yes
Number of SATA power connectors	8
Purpose	PC
ATX version	2.4
EPS version	2.92
Silent mode	No
Bearing technology	Rifle
80 PLUS certification	80 PLUS Bronze
Mean time between failures (MTBF)	100000 h
Power supply unit (PSU) form factor	ATX
Fan diameter	120 mm
Harmonized System (HS) code	84733020
