ENGLISH
2
ENGLISH
Dimensions: 140mm(L) x 150mm(W) x 86mm(H)
Package Contents: Power Supply, AC Cable, DC Cables, Cable Ties, Mounting Screws, Safety Leaflet
RM850e INCLUDED HARDWARE AND SPECIFICATIONS
CORSAIR RM850e POWER TABLE MAX LOAD MAX OUTPUT
MODEL RPS0157 +3.3V 20A
150W
PART NO. 75-005036 +5V 20A
AC INPUT RATING 100 - 240V a.c. +12V 70.8A 850W
INPUT CURRENT 10 - 5A -12V 0.3A 3.6W
FREQUENCY 47 - 63Hz +5Vsb 3A 15W
TOTAL POWER: 850W
CORSAIR RM850e POWER SUPPLY EFFICIENCY
10021050
20
95
90
85
80
75
70
EFFICIENCY (%)
SYSTEM LOAD (%)
CORSAIR RM850e POWER SUPPLY FAN NOISE CURVE
0
850
170 340 510 680
30
25
20
15
10
5
0
FAN NOISE (dB)
POWER OUTPUT (W)
input 115V a.c.
input 230V a.c.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Corsair RM1000e and is the answer not in the manual?

Corsair RM1000e Specifications

General IconGeneral
Wattage1000W
Efficiency Rating80 PLUS Gold
ModularFully Modular
Form FactorATX
Fan Size140mm
Zero RPM ModeYes
MTBF100, 000 hours
EPS Connectors2
PCIe Connectors6
ATX Connector1
Fan BearingFluid Dynamic Bearing
Input Voltage100-240V
Input Frequency47-63Hz
Output+3.3V@20A, +5V@20A, +12V@83.3A, -12V@0.3A, +5Vsb@3A
Dimensions150mm x 86mm x 160mm
Operating Temperature0°C to 50°C
Fan Bearing TypeFluid Dynamic Bearing
Connectors1 x ATX, 2 x EPS, 6 x PCIe, 4 x Peripheral
ProtectionsOVP (Over Voltage Protection), UVP (Under Voltage Protection), SCP (Short Circuit Protection), OTP (Over Temperature Protection), OPP (Over Power Protection)
