Corsair RM750x SHIFT User Manual

ENGLISH
1
ENGLISH
Dimensions: 160mm(L) x 150mm(W) x 86mm(H)
Package Contents: Power Supply, AC Cable, DC Cables, Cable Ties, Mounting Screws, Safety Leaflet
RM750x SHIFT INCLUDED HARDWARE AND SPECIFICATIONS
CORSAIR RM750x SHIFT POWER TABLE MAX LOAD MAX OUTPUT
MODEL RPS0159 +3.3V 20A
150W
PART NO. 75-005190 +5V 20A
FREQUENCY 47 - 63Hz +12V 62.5A 750W
INPUT CURRENT 10 - 5A +5Vsb 3A 15W
AC INPUT RATING 100 - 240V a.c.
TOTAL POWER: 750W
CORSAIR RM750x SHIFT POWER SUPPLY EFFICIENCY
10021050
20
95
90
85
80
75
70
input 115V a.c. input 230V a.c.EFFICIENCY (%)
SYSTEM LOAD (%)
CORSAIR RM750x SHIFT POWER SUPPLY FAN NOISE CURVE
0
750
150 300 450 600
40
30
20
10
0
FAN NOISE (dB)
POWER OUTPUT (W)

Corsair RM750x SHIFT Specifications

General

Wattage	750W
Form Factor	ATX
Efficiency Rating	80 PLUS Gold
Modular	Fully Modular
Fan Size	140mm
Zero RPM Mode	Yes
Warranty	10 Years
ATX12V Version	v2.52
Connectors	1 x ATX, 2 x EPS, 4 x PCIe, 4 x Peripheral, 10 x SATA
