Corsair RM750x SHIFT User Manual

ENGLISH
5
ENGLISH
CORSAIR RMx SHIFT SERIES CABLE INFORMATION
DESCRIPTION QTY
CONNECTORS TOTAL LENGTH 750W 850W 1000W 1200W
ATX Cable (24-pin)
610mm ± 10mm 1 1 1 1
EPS/ATX12V Cable 8-pin (4+4)
650mm ± 10mm 2 2 2 2
12VHPWR Cable (12+4) pin
650mm ± 10mm 1 1 1 1
PCIe Cable 8-pin (6+2)
750mm ± 10mm 1 1 2 2
PCIe Cable 8-pin (6+2)
650mm ± 10mm 1 2 3 4
SATA Cable (4 SATA)
800mm ± 10mm 3 3 4 4
PATA Cable (4-pin)
750mm ± 10mm 1 2 2 2

Corsair RM750x SHIFT Specifications

General

Wattage	750W
Form Factor	ATX
Efficiency Rating	80 PLUS Gold
Modular	Fully Modular
Fan Size	140mm
Zero RPM Mode	Yes
Warranty	10 Years
ATX12V Version	v2.52
Connectors	1 x ATX, 2 x EPS, 4 x PCIe, 4 x Peripheral, 10 x SATA
