6000HT PARTS LIST (CONT.)
Part # Description Quantity
35 Seat Pad Shaft M6 X 116mm 1
36 Screw M10 X 113mm 2
37 Carriage Bolt M8 X 128mm 1
38 Flat Washer 23mm DIA For 5/16” Shaft 1
39 Screw M6 X 14mm 8
40 Allen Bolt M8 X 15mm 12
41 Flat Washer 20mm DIA For 5/16” Bolt 12
42 Spacer 4
43 Screw M8 X 64mm 1
44 Screw M8 X 88mm 1
45 “Bullet” End Cap For Foot Bar 2
46 50mm End Cap 2
47 Transportation Wheel 2
48 Foot Plate Storage Hook 1
49 Dome Nut 2
50 M8 Knob 1
51 Bracket 2
52 Protection Bracket 1
53 Spring Pin 1
54 Plastic Washer 1
55 Program Card Holder 1
56 Program Card Set 1
NOTE: For your convenience, many of the parts on this list have been
pre-assembled. The parts you need for assembly are shaded and in bold.
HARDWARE PACK
x 12 PCS x 12PCS
