Cosmo P 300 User Manual

35
11.4. CONVOGLIATORE SINGOLO - ONE SIDE CONVEYOR
POS. QTY CODICE DESCRIZIONE DESCRIPTION
1 1 300.030 VITE TTQST M8X16 ROUND-HEAD SCREW M8X16
2 1 300.030 VITE TTQST M8X16 ROUND-HEAD SCREW M8X16
3 1 303.013 ROND. 8X24 UNI 6593 ZB WASHER 8X24 UNI 6593
4 1 302.005 VOLANTINO FEMM. DM40 M8 KNOB DM40 M8
5 1 620.002 CONVOGLIATORE LATERALE SINGOLO DOUBLE LATERAL CONVEYOR
6 1 303.013 ROND. 8X24 UNI 6593 ZB WASHER 8X24 UNI 6593
7 1 302.005 VOLANTINO FEMM. DM40 M8 KNOB DM40 M8
8 4 303.013 ROND. 8X24 UNI 6593 ZB WASHER 8X24 UNI 6593
9 1 620.223 STAFFA ASOLATA SLOTTED SUPPORT
10 2 300.029 VITE TE M8X20 UNI 5739 ZB HEX. HEAD SCREW M8X20 UNI 5739
11 1 303.015 RONDELLA 10X20 UNI 6591 ZB WASHER 10X20 UNI 6591
12 1 301.013 DADO AUTOBLOC. ALTO M10 ZB SELF-LOCKING NUT M10
13 1 300.003 VITE TE M10X25 UNI 5739 ZB HEX. HEAD SCREW M10X25 UNI 5739
14 1 301.013 DADO AUTOBLOC. ALTO M10 ZB SELF-LOCKING NUT M10
15 1 303.005 RONDELLA 10X40 UNI 6593 ZB WASHER 10X40 UNI 6593
16 1 620.222 STAFFA A C SOSTEGNO CONV. C TYPE SUPPORT BRACKET
17 1 300.016 VITE TE M10X20 UNI 5739 ZB HEX. HEAD SCREW M10X20 UNI 5739
18 1 300.003 VITE TE M10X25 UNI 5739 ZB HEX. HEAD SCREW M10X25 UNI 5739
19 1 620.102
KIT CONVOGLIATORE LATERALE
SINGOLO P
SINGLE SIDE CONVEYOR KIT
