18. SEQUENCE OF DISPLAY PAGES (the data and the functions are those in memory at time of delivery)
Keys for scrolling the pages on the display and positioning the cursor on the data which can be changed.
The data which can be changed, in the following descriptive list of display pages, are highlighted thus
By pressing these keys at the same time, or in any event after 15 minutes, the first page appears on the display.
Keys for : - changing the values highlighted by the cursor
– viewing the configuration options of a function, for example : or
– passing directly from one menu (series of pages) to another
H e a t E m i t t e r s
F A N C O I L S
H e a t E m i t t e r s
P A N E L S
H t g : - - - - - - - - - - - -
1 2 . 1 8 M O N D A Y
–
+
17. COMMISSIONING
Testing to be carried out when installation concluded, wiring and configuration completed and
checked.
17.
1 Testing C-Ring
Ensure that all the other controllers connected in C-Ring are :
– correctly powered by 230 V AC (or 240 V AC for UK market)
– Slave controllers or configured as SECONDARIES in
– selected on testing page
The “PRIMARY” controller sends a signal every 5 seconds via C-Ring. On all the displays appears
“??”. If the connection is positive, “OK” replaces “??” on all the displays.
If on one or more displays “OK” does not appear, this means that there is a break between the last
controller with “OK” and the first with “??”.
Examples of testing a C-Ring setup with four controllers :
– Cont.1 "OK" – Cont. 2 "OK" – Cont.3 "OK" – Cont.4 "OK" : Wiring positive
– Cont.1 "??" – Cont. 2 "OK" – Cont.3 "OK" – Cont.4 "OK" : Break between 4 and 1
– Cont.1 "??" – Cont. 2 "OK" – Cont.3 "??" – Cont.4 "??" : Break between 2 and 3
– Cont.1 "??" – Cont. 2 "??" – Cont.3 "??" – Cont.4 "??" : Break between 1 and 2
17.
2 Testing outputs
With + and – keys choose :
• output to be tested :
– VALVE 1 ; VALVE 2;
– PUMP 1 ; PUMPA 2;
•status :
– with VALVE : IDLE ; CLOSES ; OPENS
– with PUMP: ON or OFF
Check the result
26.1
C R i n g : ? ?
26.2
O u t p u t : V A L V E 1
S t a t u s : I D L E
C R i n g C o n n e c t i o n
S E C O N D A R Y
C R i n g : ? ?
