O u t p u t : Y 1 M O D U L .
S t a t u s : I D L E
M4.1
Select outputs to be tested
Select output status
24.
Output selection:
Y1 MODUL. or Y1 2 STAGES or Y1 3 STAGES ;
Y2 MODUL. or Y2 2 STAGES or Y2 3 STAGES ;
PUMP M1 ;
PUMP M2 ;
Ys ;
Status selection :
with Y... MODUL.: STOPS; OPENS; CLOSES
with Y... 2 STAGES: ON 1; ON 1+2; OFF
with Y...3 -STAGE: ON 1; ON 2; ON 1+2; OFF
with M1 PUMP AND M2 PUMP
ON; OFF
with Ys: 0 VOLT; 5 VOLT; 10 VOLT
M4. TESTING
Ref. Display Description Notes Sect
