Open the cart
As shown in figure, fasten the Upper part to a mounting position on the
forefoot, and hear it “click” into place.
Step 3
Install the rear bumper
Insert the guard bar into the
mounting hole of the Footwall as
shown in the figure, and install it in
place. Then fix it with screws.
Step 4
Install the wheels
Put the front and rear wheels into the
corresponding mounting holes of the
Footwall, and install the wheels firmly
in place.
Step 5
Install mirrors, rear wing
Place the rearview mirror and the rear wing on
the installation position of the panel as shown
in the figure.
Step 6
Accessories details
Assembly Instructions
Install the forefoot
Press the buttons on both sides of the
forefoot and insert it into the mounting
slot of the footwall.
Rotate the forefoot to the upright position
as shown in the figure,and install it in
place with a “click” sound.
Step 1
Install the Upper part wheel
As shown in the figure, install the front
and rear wheels and sub-fixing parts of
the upper part to the installation
position of the upper part until the
fixing parts are fastened on the upper
part.
Step 2
Rear view mirror
Seat cushion
Rear bumper
Rear wheel
Front wheel
Footwall
MUSIC BOX
Upper part
Forefoot
04 05
