CountyLine 17455 - Page 23

Operator’s Manual
17455 Front Tine Tiller
For additional information email info@ardisam.com or call 800-345-6007 M-F 8-5 CST
23
REF.
NO.
PART # DESCRIPTION QT Y.
1 1401 BOLT,HHCS5/16-18X1-1/4”GR5 1
2 1407 SPRING, FORWARD ARM 1
3 1413 PULLEY, FORWARD IDLER 1
4 1416 PIN,LINK 1
5 1418 PIN, COTTER 1
6 1714252 WHEEL&TIREASSY11.0X1.75 2
7 3228 HAIRPIN2.5MMX51.25MM 4
8 2108 NUT,NON-LOCKINGHEX3/8-16 1
9 17625 SHIELD,ORANGEFRONTTINE 1
10 17621 FRAME, ORANGE FRONT TINE 1
11 3157 LEVER,DEPTHREGULATOR 1
12 50175 WASHER,FLAT12MM 4
13 3182A BELT GUIDE & MOUNT 1
14 3196 BOLT,HHCS1/4-20X7-1/2”GR5 2
15 --- --- ---
16 --- --- ---
17 17616 SHIELD,FRAMEORANGEFT 1
18 3305 ENGINE, 6.75 T.R. BRIGGS 1
19 17623 TAIL MOUNT, LOWER ORANGE FT 1
20 17622 TAIL MOUNT, UPPER ORANGE FT 1
21 3331 SHAFT,WHEEL1/2” 1
22 3332 SHAFT,TAILMOUNTHINGE1/2” 1
23 3360 IDLER ARM, FORWARD 1
24 3364 KEY,SQUARE3/16”X5/8” 1
25 3370 BELT, FORWARD 1
26 48300 BOLT,HHCS5/16-18X2-1/4”GR5 1
27 53596B YOKE,CABLE 1
28 60G56 NUT,BI-WAYLOCK5/16-18 4
29 63118 BOLT,HHCS1/4-20X1/2” 6
30 67538 NUT,HEXNYLOC1/4-20 8
REF.
NO.
PART # DESCRIPTION QT Y.
31 69170 PIN, DETENT 5/16” X 2” 1
32 --- --- ---
33 719 WASHER,SPRINGLOCK3/8” 1
34 744 SPACER, BELT GUIDE 2
35 90140 BOLT,HEXHD5/16-18X3-1/4” 1
36 WF516 WASHER,FLAT5/16” 3
37 WL14 WASHER,SPRINGLOCK1/4” 2
38 90141 BOLT3/8-16X1SFHHGR5ZNW
PATCH
4
BUMPER GUARD PARTS
39 1516 BOLT,SOCFLANGEHEXHD,1/4-20
X 3/4”
4
40 17620 HANDLEBAR,LOOPLOWERORANGE 1
41 17624 COVER,4HOLEORANGEFT 1
42 67538 NUT,HEXNYLOC1/4-20 4
43 WF14 WASHER,FLAT1/4” 4
DRIVE PULLEY PARTS
44 807 BOLT5/16-24X3/4W/PATCHBHSCS 1
45 809 WASHERFLAT1”ODX.047SPACER 1
46 3207 SPACER.055THICKX.755IDX1.244
OD
2
47 741 SPACER DRIVE PULLEY
.900”
1
48 3178 PULLEY SINGLE GROOVE
ENGINE
1
MOTOR MOUNT & HOOD PARTS
