CountyLine PHD 100 - Page 25

Assembly 25
602378 REV AA
12/18/2018
PHD100 POST HOLE DIGGER ASSEMBLY PARTS LIST
REF PART QTY DESCRIPTION
1 602390 1 BOOM
2 602376 1 A-FRAME
N/A 602415 1 GEAR BOX, COMPLETE (WITH 3, 4, 5, 6)
3 S24070100 1 GEAR BOX
4 602389 1 LUG BRACKET
5 S24075100 1 INPUT GUARD
6 602383 1 OUTPUT GUARD
7 602416 1 PTO SHAFT STORAGE BRACKET
8 S24087600 1 MANUAL CANISTER
9 585648* 2 1/4" x 3/4" SELF TAPPING SCREW
10 S07071500 1 3/4" TOP LINK PIN
11 S07090100* 1 7/16" LYNCH PIN
12 S24117000 1 DRIVE LINE, LARGE, SLIDE COLLAR
13 602386 1 HANDLE, PHD
14 75393 1 GRIP
15 S07095400* 3 LOCK PIN, 5/16" x 1-3/8"
16 30007* 2 7/8" NF HEX NUT
17 30008* 2 7/8" LOCK WASHER
18 37009* 2 7/8" NF JAM NUT
19 1009383A 2 PIN, LIFT ARM, 7/8" x 6.78
20 S17010500* 2 1/2" NC HEX NUT
21 S17030300* 2 1/2" LOCK WASHER
22 S17056600* 2 1/2" NC x 3-1/4" HEX BOLT, GRADE 5
23 602380 2 LEG
24 1036156* 1 3/8" NC x 3" SHEAR BOLT, GRADE 2
25 S17030100* 1 3/8" LOCK WASHER
26 S17010100* 1 3/8" HEX NUT
27 612141 1 M6 x 25MM SET SCREW
28 612140 1 M6 JAM NUT
* OBTAIN LOCALLY
