3. Attach the 2 side panels (E) and front panel (D)
to the legs using 12 pcs M6 x 10 screws (AA) and
12 pcs M6 nuts (BB). Tighten with wrench (FF).
F
G
H
I
AA
M
ASSEMBLY INSTRUCTIONS
1. Check that the control knob (M) for the gas
supply system is turned to the “OFF” position
before starting any assembly.
2. Attach right front leg (G), right back leg (H) and
2 left legs (F) to the metal stand (I) using 4 pcs
M6 x 10 screws (AA). Tighten with wrench (FF).
1-888-897-1222 | Page 7
