7. Place propane gas tank (not included) into the
metal stand (I). Make sure the gas tank sits on the
metal stand (I) completely. Turn the preassembled
wing screw on the outer part of metal stand (I)
clockwise to secure the propane gas tank tightly.
9. Remove the rubber cap on the electronic igniter
(Q) by unscrewing and slide battery (L) into the
battery slot. Make sure the positive side of the
battery faces outwards. Screw the electronic
igniter cap (Q) over the battery tightly.
CYLINDER VALVE
PRESSURE
RELIEF VALVE
BLEED-OFF
VALVE
BLACK COUPLING NUT
REGULATOR
turn clockwise to connect
turn clockwise
to reseal
8. Turn the cylinder valve on the tank
clockwise to close the propane tank.
Attach the preassembled regulator
from the table top (B) to the cylinder valve
by turning the regulator coupling nut
clockwise. Make sure it is fastened
securely and tighten connections by hand
only.
Q
L
I
1-888-897-1222 | Page 9
