HOW TO INSTALL
Installation Guide
Connect the orange inlet hose into the tap water supply
pipe1. Connect the reject water drain hose2.
Main Water
Supply Valve
For own dedicated
120 V~ 60 Hz, AC only
electric outlet
Tap water supplying hose
(orange) tubing
Reject water outlet hose
(blue) tubing (CHPI-620L)
1
2
