01
90 degrees
Handlebar
Allen key 3
01 Check
Your bike comes with the handlebar
parallel to the wheels and frame.
03 Secure
Use Allen key 3 to tighten the two
screws securely as shown. This will
keep your handlebar in place. Be sure
to insert the short end of the Allen
key for the greatest purchase when
tightening, then test it to make sure it’s
fully secure by blocking the front wheel
between your legs and trying to move
the handlebar from left to right.
02 Rotate
Turn the handlebar 90 degrees clockwise
until it’s at a right angle to the rest of
the bike.
Warning: the front brake disc marked in the
diagram must end up on the left side of the
wheel. If you see the disc brake is sitting
incorrectly on the right-hand side, turn the fork
in the counter-clockwise direction to rectify.
Front
brake disc
