INSTALLING THE WALL PLATE (OPTIONAL)
Do not connect high current devices such as hair dryers to this receptacle.
Maximum current rating of the receptacle is 5A at 12V. The power supply
should be turned off when connecting cables/wires.
1. Choose a location for the wall plate. The wall plate may be ush mounted
to your wall. The wall plate is also compatible with most standard
electrical boxes. To mount, cut a hole in the wall to t the wall plate or
electrical box.
2. Drill holes on the wall according to the screw locations of the wall plate or
your electrical box.
3. Turn the wall plate around to the back side of the unit.
4. Connect the black & red DC wires to your 12V power source. Use as a
minimum 14 AWG wire.
5. Connect the antenna coaxial cable to “ANTENNA INPUT” F connector (#1)
and tighten until nger tight. (The coax cable is to be routed through the
ceiling and wall to the chosen wall plate location).
6. (OPTIONAL) Connect the Satellite TV cable to “SATELLITE TV INPUT” F
connector (#2) and tighten until nger tight.
7. (OPTIONAL) If you have a second television outlet in your caravan, for
instance an external entertainment hatch, connect the secondary TV outlet
cable to “TV2 OUTPUT” F connector (#3) and tighten until nger tight.
8. Turn the wall plate to the front side.
9. Fix the wall plate to the wall with the supplied screws.
10. Connect the TV cable to “TV1 OUTPUT” F connector (#4) and tighten until
nger tight. Connect the other end of the TV cable to the “Antenna In”
coax port on your TV.
11. Press the “ON” switch on the front of the wall plate/power supply, and
conrm that the light turns on.
