EXTERNAL INTERFACES
Table 4-1. RF Switch Pin Assignment (J5)
Pin # Signal Name Remarks
A Status Relay 1 NO Relay 1 normally-open contact. Function defined by
switch S1.
B Status Relay 1 NC Relay 1 normally-closed contact. Function defined by
switch S1.
C Status Relay 1 COM Relay 1 common contact.
D Status Relay 2 NO Relay 2 normally-open contact. Function defined by
switch S1.
E Status Relay 2 NC Relay 2 normally-closed contact. Function defined by
switch S1.
F Status Relay 2 COM Relay 2 common contact.
G External Latching I/L Open from Return (pin H) for latching Beam Off
interlock.
H External Latching I/L Rtn Latching interlock return.
J External Non-Latching I/L Open from Return (pin K) for non-latching (RF Inhibit)
Interlock.
K Ext. Non-latch I/L Rtn Non-Latching interlock Return.
L RF Inhibit Open from Return (pin M) for non-latching RF Inhibit.
M RF Inhibit Rtn RF Inhibit Return.
N Reset to Defaults Shorting this to return (pin P) while unit is turned on will
reset the serial communication parameters to the
factory defaults.
P Reset to Defaults Rtn Reset Return.
R WG SW POS 1 OUT Drive to Waveguide Switch for position 1
S WG SW GND Waveguide Switch Drive Return
T WG SW POS 2 OUT Drive to Waveguide Switch for position 2
U WG SW POS 1 IN Contact indicating Waveguide Switch position 1
V WG SW GND Waveguide Switch position return
W WG SW POS 2 IN Contact indicating Waveguide Switch position 2
X FAULT Fault relay from other amplifier
Y GND Digital Ground
