Craftmade Bellows II - Unpacking Your Fan; Parts Inventory

page 2
2. Parts Inventory.
a. canopy. 1 piece
b. hanging bracket. 1 piece
c. downrod and hanging ball. 1 piece
d. remote control receiver. 1 piece
e. wall plate.1 piece
f. remote control cover. 1 piece
g. wall control. 2 pieces
h. small fitter plate (for use without light kit).
1 piece
i. large fitter plate (for use with light kit).1 piece
j. faceplate. 3 pieces
k. yoke cover. 1 piece
l. glass shade. 1 piece
m. light kit fitter. 1 piece
n. metal cover. 1 piece
o. canopy cover (in hardware pack). 1 piece
p. finial plate (pre-attached to light kit fitter).
1 piece
q. finial (pre-attached to light kit fitter). 1 piece
r. motor assembly. 1 piece
s. hardware packs
1. Unpacking Your Fan.
Carefully open the packaging. Remove items
from Styrofoam inserts. Remove motor assembly
and place on carpet or Styrofoam to avoid
damage to finish. Do not discard fan carton or
Styrofoam inserts should this fan need to be
returned for repairs.
Check against parts inventory that all parts have
been included.
IMPORTANT REMINDER: You must
use the parts provided with this fan for
proper installation and safety.
r
k
i
h
s
a
e
b
c
d
f
j
l
m
p
q
n
w/ remote
w/wall
control
g
o
DIM ON
11
-
22
-
required bulbs:
2 x 9 watt medium base LED bulbs (included)
