Your line trimmer has been designed to operate over
a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper
tool care and regular cleaning.
_,WARNING! Before performing any
maintenance, switch off and unplug the toot.
[] Regularly clean the ventilation slot in your line
trimmer using a soft brush or dry cloth.
[] Regularly clean the cutting line and trimmer head
using a soft brush or dry cloth.
[] Regularly use a blunt scraper to remove grass and
dirt from the underside of the safety guard.
_WARNING! When servicing, use only
identical replacement parts. Use of any other parts may
create a hazard or cause product damage.
REPLACING THE TRIMMER HEAD
See Figure 14.
[] Lay the product on a flat stable surface with the
trimming head facing upward.
[] Rotate the backing flange until one of the notches is
aligned with the hole in the gear head.
[] Insert the spindle lock rod into the hole to lock the
spindle.
[] Unscrew the trimmer head clockwise to remove.
LINE REPLACEMENT
See Figure 15.
[] Unplug the line trimmer.
[] Press and hold the release button [A] on the trimmer
head housing. The trimming line [C] can be replaced
while the button is pressed.
[] After inserting new trimming tine [C], make sure that
it sticks out evenly from both sides of the trimmer head.
NOTE: Always use .080" (2mm) round trimmer
monofitament line as replacement line.
SEARS item # 71.85606.
_iL WARNING! Only use the appropriate type of
cutting line.
STORmNG THE TRIMMER
[] Clean all foreign material from the trimmer.
[] Store it in a place that is inaccessible to children.
[] Keep away from corrosive agents such as garden
chemicals and de-icing salts.
11 -- English
