Craftsman 917.273421 - Page 45

ENGINE
TRACTOR - - MODEL NUMBER 917.273421
KEY PART
NO. NO. DESCRIPTION
1 160588
2 17720410
3 ....... .
4 149723
5 'L56796
6 156799
8 150176
10 160624
11 ........
_3 ........
16 STD551237
17 17490624
23 159880
29 137180
31 151346
32 161493
33 123487X
34 106082X
35 17490512
37 8543R
39 109227X
40 3645J
41 139277
44 17490612
94 160858
95 160629
97 M73040800
99 160771
100 160772
Control Throt RH BIkPdl
Screw Hex Thd Cut 1/4-20x5/8 T
Engine (See Breakdown)
Kawasaki Model No. FD59OV
MufflerAsm Twin Lo-Tone
Exhaust Asm RH 1B HP Vert
ExhaustAsm LH 18 HP Vert
Bolt 5/16-18 Uric x 3/4 w/Sems
Sl'_eldHeat Kawasaki
Washer LockHvy Helical1/4 (Order from
Engine Manufacturer)
Gasket Muffler (Order from Engine
Manufacturer)
Washer LockExt Tooth3/8
ScrewThdrol3/8-16 X 1-1/2 "It
ShieldBrowning
Kit SparkArrestor
Tank Fuel
Cap Asm Fuel w/Gauge Vented
Clamp Hose BIk
Pad Spacer
Screw Thdrol 5/16-18 x 3/4
Line Fuel 54"
Pad Idler
Bushing
Stem Fuel Tank
Scrw t-lexTl_lrol 3/8-15 x 3/4
FilterAsm Engine Kawasaki
Trim, Seal
NutHex (Order fromEngine Manufacturer)
Nut Serrated WB Ms-1.25
BracketAsm. Pivot LH
BracketAsm. Ph,'olRH
NOTE: Allcomponentdimensionsgivenin U.S. inches
t inch= 25.4 mm
45
