BRIGGS & STRATTON MODEL NO. 12H802
,..4-CyCLEENGINE ..................................... TYPE NO. 1978-E1
KEY PART KEY PART
NO, NO+ DESCRIPTION NO+ NO. DESCRIPTION
227 492349
230 67072
258 94512
284 94511
300 497838
304 493293
305 94744
306 224324
307 94515
332 94877
333 802574
334 94731
337 802592
356 497833
358 497316
363 19069
383 89838
387 496115
447 95013
455 225121
456 281503
459 281505
461 94943
515 263073
523 495264
524 280393
525 495265
529 281299
562 94852
572 224328
592 231082
601 93053
605 225103
606 224815
608 497680
lncl: 94904
94908
613 94231
615 94474
616 263175
6t7 270344
620 499835
621 396847
625 497465
Lever, Governor 634 - - + *'* Washer, Shaft (Sold in
Washer, Thrust Kit Only)
Screw, Hex Head 635 66538 Elbow, Spark Plug
Screw, Hex Head 670 280512 Spacer, Fuel Tank
Muffler, Exhaust 670A 493823 " Spacer, Bracket
Housing, Blower 741 262598 Gear, Timing
Screw, Sems 842 280966 * Seal, O-Ring
Shield, Cylinder 843 272616 Sleeve, Lever
Screw, Hex Head 847 495263 Tube Assembly, Oil
Nut, Flywheel 851 493880 Terminal, Ignition Cable
Armature, Magneto 869 213512 Seat, Intake Valve
Screw, Sems 870 213513 Seat, Exhaust Valve
Plug, Spark 871 262001 Guide, Exhaust Valve
Wire, Ground 63709 Guide, Intake Valve
Gasket Set 922 262640 Spring, Brake
Puller, Flywheel 923 493442 Brake Assembly
Wrench, Spark Plug 925 281145 Cover, Linkage
Primer, Carburetor 930 28t 136 Guard, Finger
Screw, Hex 957 397974 Cap, Fuel Tank
Cup, Starter 966 496116 Base, Air Cleaner
Retainer, Starter 967 491588 Filter, Air
Pawl, Rachel 968 281340 Cover, Air Cleaner
Screw, Shoulder 969 94872 Screw, Hex Head
Spring, Retainer 971 94873 Screw, Hex Head
Cap, Oil Filler 971A 94749 Screw, Hex Head
• Seal, Filler Tube 972 495224 Tank, Fuel
Tube, Oil Fill 975 493640 Bowl, Float
Grommet 977 498261 Gasket Set, Carburetor
Bolt, Governor Lever t036 499341 Label Kit, Emission
Baffle, Cylinder 1095 498258 Gasket Set, Valve
Nut, Hex Overhaul
Clamp, Hose 2500 12J802-2915 Replacement Engine
Cover, Control 498826 Replacement Shortblock
Strap, Bracket
Starter, Rewind RPbl Settings: Low: 1900-2100; High:
Screw, Hex 3000-3200
Nut, Hex
Screw, Hex Head * Included in Gasket Set (497316)
Fastener
Crank, Governor "" Included in Carburetor Kit (498266)
"'" Seal, Intake Elbow
Bracket, Carburetor "*" included in both Carburetor Kit (498260),
Switch, Stop and Carburetor Gasket Set (498261)
Tube, Fuel Intake
NOTE:
Included in both Gasket Set (497316),
Set (497316) and Valve overhaul
Gasket Set (498528)..
All component dimensions given in U.S inches
1 inch = 25_4 mm
