13. With the tank cover in an upside down position, slide the
cartridge filter
14
down over the lid cage, pushing until
the filter seals against the cover. Fig. 5.
14. Place filter retainer
15
into the top of the cartridge filter
14
. Fig. 6.
15. Hold the tank cover with one hand, turn the handle on
the filter retainer
15
clockwise to tighten, locking the
cartridge filter
14
into place. Fig. 7.
16. To remove the cartridge filter
14
for cleaning, again hold
the tank cover and turn the filter retainer
15
counter-
clockwise to loosen and remove. Fig. 8.
17. Slide the cartridge filter
14
off the lid cage. Fig. 9.
18 To clean cartridge filter
14
shake or brush off excess dirt.
Fig. 10.
Fig. 5
Fig. 6
Fig. 7
Fig. 8
Fig. 9
Fig. 10
5
