6
ENGLISH
UNPACKING
WARNING:
VERIFY THAT THE
POWER CORD IS DISCONNECTED FROM THE
OUTLET.
1. Undo the latches
10
.
2. Lift the power head
12
off the collection
tank
5
.
3. Remove the contents from inside the
collection tank
5
; make sure you have all
contents as listed on page 3.
ASSEMBLY
Caster System Assembly
4. Turn the collection tank on its side and
insert the four caster feet
6
into the slots
on the collection tank and tighten with the
pre-installed screws. Verify that the caster
feet
6
are mounted correctly. Do not over-
tighten screws. Fig. 1.
Fig. 1
GENERAL SET UP
5. Your vacuum comes ready for dry vacuum
cleaning. If the cartridge filter is not
installed, refer to page 9 for installation
instructions.
6. For wet vacuum cleaning, remove the
cartridge filter, and install the supplied foam
wet filter. See page 10 for the foam wet
filter installation instructions.
7. Place the power head back on the collection
tank and secure into place using the latches.
8. Insert the locking end of the hose
17
into
the vacuum port on the collection tank
5
and lock into place. Fig. 2.
Fig. 2
9. Choose the desired accessory
20
21
23
and/or extension wands
18
and insert onto
the end of the hose
17
. Fig. 3.
Fig. 3
10. Plug the power cord into the outlet.
Turn the motor on by flipping the on/off
switch
16
to the ‘I’ ON position and begin
vacuuming. Fig. 4.
Fig. 4
WARNING:
ONCE YOU HAVE
COMPLETED VACUUMING, FLIP THE
ON/OFF SWITCH TO THE ‘O’ OFF POSITION
AND UNPLUG THE POWER CORD FROM THE
OUTLET. O = OFF I = ON
