Craftsman CMXTEPA0036 - Page 6

6
24kW, 29kW
18W
Fig. 3 Fig. 4
Fig. 5
Do not install upside down
or on its side
Fig. 6
Water Pre-
Filter
118
º
F
temp
Fig. 3 Fig. 4
Fig. 5
Do not install upside down
or on its side
Fig. 6
Water Pre-
Filter
118
º
F
temp
a. Remove the appliance cover. (Heater cover) (figure 3)
b. Mount the unit on the wall with 4 screws at the marked points (figure 4)
c. Make sure the unit is leveled horizontally, with water inlets and outlets at the bottom (fig.5)
D. Make sure the unit includes the water pre-filter (fig.6)
