Craftsman Professional PYT9000 User Manual

35
PARTS LIST
Ref.
No.
Part No. Description
1 710-04095 Hex Head Screw, 3/8-16:1.00
2 710-0514 Hex Head Screw, 3/8-16:1.00
3 710-0643 Hex Head Screw, 5/16-18:1.00
4 711- 04998 LH Drag Link
5 711-04999 RH Drag Link
6 912-0240 Jam Nut, 7/16-20
7 712-04065 Flangelock Nut, 3/8-16
8 712-0459 Flangelock Nut, 7/16-20
9 712-3004A Flangelock Nut, 5/16-18
10 717-1550F Steering Gear
11 717-1554 Steering Pinion Gear
12 923-0448A Ball Joint, 7/16-20
13 936-3004 Flat Washer, .406 X .875 X .105
14 736-3084 Flat Washer, .51 X 1.12 X .06:HT
15 634-04405-4042 Rim Assembly
16 738-04263 Steering Shaft, .625 OD X 24.25 LG
17 738-04363 Shoulder Spacer, .385X 1.25 X .3025
18 741-04237B Hex Flange Bearing 5/8 PM
19 783-06043-0637 Steering Support Bracket
Ref.
No.
Part No. Description
20 638-04022-0637 RH Axle Assembly
21 638-04028-0637 LH Axle Assembly
22 710-0395 Hex Head Screw, 5/16-18:2.25
23 710-0859 Hex Head Screw, 3/8-16:2.50
24 710-3180 Hex Head Screw, 5/16-18:1.75
25 912-0214 Hexlock Nut, 3/8-24
26 712-04063 Flangelock Nut, 5/16-18
27 714-0162 Cotter Pin, 5/32:1.25
28 719-04413A Pivot Bar Axle
29 934-0255 Tubeless Air Valve
30 748-04065-0637 Steering Block
31 748-04068 Spacer, .71 ID X .125 OD X .56LG
32 750-05280 Spacer, .385 X 1.00 X 1.5075
33 731-05674 Bumper Cap
34 736-04228A Flat Washer, .781ID x 1.590OD
35 631-04415 Steering Wheel
36 731-06825 Steering Wheel Cap
37 634-04406-0961 Wheel Assembly
38 734-1731-0901 Tire
Steering and Axle — Model No. 247.28888

Craftsman Professional PYT9000 Specifications

General

Deck Material	Steel
Transmission Type	Hydrostatic
Type	Riding Mower
Cutting Height	1.5 to 4 inches
Blades	3 blades
