Craftsman TINE DETHATCHER 486.24312 User Manual

3
HARDWARE PACKAGE CONTENTS
A
J
N O
K L
B
D
G
H
I
SHOWN FULL SIZE
NOT SHOWN FULL SIZE
C
E
F
M
KEY QTY DESCRIPTION
A 12 Carriage Bolt, 5/16-18 x 1" Lg.
B 2 Hex Bolt, 5/16-18 x 1" Lg.
C 4 Hex Bolt, 3/8-16 x 1"
D 2 Hex Bolt, 3/8-16 x 1-1/4"
E 4 Carriage Bolt, 3/8-16 x 1-1/2"
F 4 Spacer, .8" x 1" x .5"
G 4 Flat Washer, 5/8" SAE
H 14 Nylock Nut, 5/16-18
KEY QTY DESCRIPTION
I 10 Nylock Nut, 3/8-16
J 1 Clevis Pin, 3/8" x 3/4"
K 6 Hairpin Cotter, 1/8" (large)
L 1 Hairpin Cotter, 3/32" (small)
M 1 Axle Bushing
N 2 Keeper Plate
O 1 Handle Grip
