Part name Order number Quantity
... ... NEMA 17/40 Stepper motor 20mm shaft be.000.007 * 1
... ... Filament drive gear bm.000.025 * 1
... ... ... Screw - Set screw M3L4 - DIN913_M3L4 at sc.002.004 1
... ... Bearing - lament - V625ZZ bm.001.001 * 1
... ... Extruder Spring bm.000.014 * 1
... ... Screw - Allen key M3L10 - DIN912_M3L10 sc.002.008 4
... ... Screw - Allen key M5L10 - DIN912_M5L10 sc.002.017 2
... ... Ext top FFC assy pr.001.024 1
... ... ... Ext top FFC sm.001.006 1
... ... ... ma19 Ptfe topholder ma.001.007 * 1
... ... Ext front FFC sm.001.005 1
... ... Hotend - assy pr.000.003 * 1
... ... ... ma19 Peek ma.001.006 1
... ... ... ma19 Ptfe washer ma.001.008 1
... ... ... Nozzle - MK8 0.4mm bm.000.016 1
... ... ... ma19 Cuhead w/Rubber ma.001.005 1
... ... ... ma24 Peekholder ma.001.015 1
... ... Screw - Washer M6 - DIN125_M6 sc.001.003 1
... ... Screw - Nut M6 - DIN934_M6 sc.003.004 1
... sm23_kabeltarto painted Cable holder sp.000.002 * 1
... Screw - D head M4L6 - DIN7380_M4L6 sc.002.003 6
... PCB - FFC v2.0 el.000.001 * 1
... sm29_ffcleszorító - FFC gripper sp.000.004 * 1
... Screw - Allen key M3L8 - DIN912_M3L8 Nickel plated sc.002.013 2
Cable - HMI LCD ca.001.001 * 1
Kapcsoloanya - switch nut ma.000.002 * 1
Screw - D head M2.5L1 2 - DIN7380_M2.5L1 2 sc.002.001 2
Spacer 4.2 X 8 X 3 - LCD bm.000.030 * 4
PCB - HMI v2.0 FFC el.000.004 * 1
... PCB - HMI v2.0 FFC assy el.000.005 1
... LCD - 2.8” 320 x 240 - ER-TFT028-4 be.000.005 1
Spacer M3, Nut-Nut, 15mm LCD bm.000.031 * 4
HMI cover - CBP be.000.004 1
Screw - Allen key M3L6 - DIN912_M3L6 Nickel plated sc.002.012 4
Motor - NEMA17-26 + Damper + pulley assy pr.000.004 * 3
... NEMA 17/40 Stepper motor 26mm shaft be.000.008 * 1
... NEMA 17 Vibration damper bm.000.023 1
... Screw - Allen key M3L6 - DIN912_M3L6 Nickel plated sc.002.012 2
... Pulley GT2 20 teeth bm.000.024 1
... Screw - Set screw M3L4 - DIN913_M3L4 at sc.002.004 1
... Screw - Allen key M3L4 - DIN912_M3L4 Nickel plated sc.002.011 1
Screw - Allen key M3L6 - DIN912_M3L6 Nickel plated sc.002.012 6
Cable - Motor 12cm ca.000.003 * 1
Cable - Motor 19cm ca.000.005 * 1
Cable - Motor 32cm ca.000.006 * 1
