CRC SmartWasher SW-23 - Description and Operation; Technical Data

BIOREMEDIATING parts washing system
SmartWasher
®
USER INSTRUCTION MANUAL
ORIGINAL INSTRUCTIONS
page 4 of 80
4. Description and operation
4.1. Tecnical data
SW-23 SW-25 SW-28 SW-37
Electrical connection
Type of current V/~/Hz 220 V/AC – 50/60 Hz
Connected load pump W 45 45 45 45
Electrical fuses A 1 1 1 1
Performance data
Heating output kW 1.0
Working pressure Bar 0.3 0.3 0.3 0.3
Flow rate pump Litre/min 18 18 18 18
Adjustable thermostat °C 40 – 46 40 – 46 40 – 46 40 – 46
Container capacity Litre 60 95 95 95
Load capacity Kg 180 kg 225 kg 225 kg 450 kg
Noise emission (IEC 60704-1)
Sound pressure level dB(A) < 60
Device vibrations (ISO5349)
Washing brush m/s² < 0.62
Sizes and weights
Overall dimensions mm 109x69x107 90x67x102 119x97x107 122x89x114
Inside sink dimensions mm 69x58x20 69x44x20 104x58x20 84x69x20
Empty weight Kg 32 37 42 70
