8
ENGLISH
RECEIVER PLACEMENT
BLADE ASSEMBLY
Hook the motor onto the left hook, then route the wiring.
1 2 3
Tip: Blade screw washers can be placed on each screw before installing the blades. Align
the holes in the blades with the screw holes in the motor. Secure and sevure all screws once
all blades have been hooked and installed. Before permanently attaching the screws, repeat
this process with the remaining blades. Tighten the blade screws twice.
Screw
Blade arm
Washers
1
2
To Next Page
