Creative Play S110 - Installation Steps; Step 1: Attach Timbers to Support Beam; Step 2: Attach Playtec Cover

pg 5 of 7
REF: S110 - SINGLE SWING FLAT SEAT
Attach the TIMBERS S1 to the SUPPORT BEAM
Using 8x FM 80 ‘Brass Screws’ / 10x SMALL CAPS
Attach PLAYTEC COVER to the TIMBERS S1
Using 12x FM 80 ‘Brass Screws’
1
2
Installation Instructions
NOTES:
EACH SIDE
S1S1
EACH SIDE
:NOTES
